Elektrolytkondensatoren aus Aluminium
| Foto | Herst. Teil # | Verfügbarkeit | Preis | Menge | Datenblatt | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SEK332M6R3STCAP ALUM 3300UF 20% 6.3V RADIAL |
2,553 | - |
|
Datasheet |
Bulk | SEK | Active | 3300 µF | ±20% | 6.3 V | 120mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.1 A @ 120 Hz | 1.32 A @ 10 kHz | - | 0.197 (5.00mm) | 0.512 Dia (13.00mm) | 0.827 (21.00mm) | - | Through Hole |
|
SEK3R3M100STCAP ALUM 3.3UF 20% 100V RADIAL |
3,318 | - |
|
Datasheet |
Bulk | SEK | Active | 3.3 µF | ±20% | 100 V | 40.21Ohm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 29 mA @ 120 Hz | 40.6 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
SEK3R3M160STCAP ALUM 3.3UF 20% 160V RADIAL |
2,934 | - |
|
Datasheet |
Bulk | SEK | Active | 3.3 µF | ±20% | 160 V | 60.32Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 36 mA @ 120 Hz | 57.6 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.433 (11.00mm) | - | Through Hole |
|
SEK3R3M250STCAP ALUM 3.3UF 20% 250V RADIAL |
2,715 | - |
|
Datasheet |
Bulk | SEK | Active | 3.3 µF | ±20% | 250 V | 60.32Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 42 mA @ 120 Hz | 67.2 mA @ 10 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.433 (11.00mm) | - | Through Hole |
|
SEK3R3M350STCAP ALUM 3.3UF 20% 350V RADIAL |
2,774 | - |
|
Datasheet |
Bulk | SEK | Active | 3.3 µF | ±20% | 350 V | 80.42Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 47 mA @ 120 Hz | 84.6 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
|
SEK3R3M400STCAP ALUM 3.3UF 20% 400V RADIAL |
3,726 | - |
|
Datasheet |
Bulk | SEK | Active | 3.3 µF | ±20% | 400 V | 80.42Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 47 mA @ 120 Hz | 84.6 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
|
SEK470M010STCAP ALUM 47UF 20% 10V RADIAL |
2,306 | - |
|
Datasheet |
Bulk | SEK | Active | 47 µF | ±20% | 10 V | 6.21Ohm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 75 mA @ 120 Hz | 90 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
SEK470M350STCAP ALUM 47UF 20% 350V RADIAL |
2,351 | - |
|
Datasheet |
Bulk | SEK | Active | 47 µF | ±20% | 350 V | 5.65Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 240 mA @ 120 Hz | 432 mA @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.417 (36.00mm) | - | Through Hole |
|
SEK470M400STCAP ALUM 47UF 20% 400V RADIAL |
2,840 | - |
|
Datasheet |
Bulk | SEK | Active | 47 µF | ±20% | 400 V | 5.65Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 240 mA @ 120 Hz | 432 mA @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.417 (36.00mm) | - | Through Hole |
|
SEK471M063STCAP ALUM 470UF 20% 63V RADIAL |
3,146 | - |
|
Datasheet |
Bulk | SEK | Active | 470 µF | ±20% | 63 V | 280mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 800 mA @ 120 Hz | 1.12 A @ 10 kHz | - | 0.197 (5.00mm) | 0.512 Dia (13.00mm) | 1.024 (26.00mm) | - | Through Hole |
|
SEK471M100STCAP ALUM 470UF 20% 100V RADIAL |
3,210 | - |
|
Datasheet |
Bulk | SEK | Active | 470 µF | ±20% | 100 V | 280mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 875 mA @ 120 Hz | 1.225 A @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
SEK471M6R3STCAP ALUM 470UF 20% 6.3V RADIAL |
2,613 | - |
|
Datasheet |
Bulk | SEK | Active | 470 µF | ±20% | 6.3 V | 730mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 280 mA @ 120 Hz | 336 mA @ 10 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.453 (11.50mm) | - | Through Hole |
|
SEK472M010STCAP ALUM 4700UF 20% 10V RADIAL |
3,436 | - |
|
Datasheet |
Bulk | SEK | Active | 4700 µF | ±20% | 10 V | 80mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.41 A @ 120 Hz | 1.692 A @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 0.984 (25.00mm) | - | Through Hole |
|
|
SEK472M6R3STCAP ALUM 4700UF 20% 6.3V RADIAL |
3,338 | - |
|
Datasheet |
Bulk | SEK | Active | 4700 µF | ±20% | 6.3 V | 100mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.32 A @ 120 Hz | 1.584 A @ 10 kHz | - | 0.197 (5.00mm) | 0.630 Dia (16.00mm) | 0.984 (25.00mm) | - | Through Hole |
|
|
SEK4R7M160STCAP ALUM 4.7UF 20% 160V RADIAL |
2,385 | - |
|
Datasheet |
Bulk | SEK | Active | 4.7 µF | ±20% | 160 V | 42.35Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 43 mA @ 120 Hz | 68.8 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.433 (11.00mm) | - | Through Hole |
|
|
SEK4R7M200STCAP ALUM 4.7UF 20% 200V RADIAL |
3,910 | - |
|
Datasheet |
Bulk | SEK | Active | 4.7 µF | ±20% | 200 V | 42.35Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 50 mA @ 120 Hz | 80 mA @ 10 kHz | - | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.433 (11.00mm) | - | Through Hole |
|
|
SEK4R7M350STCAP ALUM 4.7UF 20% 350V RADIAL |
2,395 | - |
|
Datasheet |
Bulk | SEK | Active | 4.7 µF | ±20% | 350 V | 56.47Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 55 mA @ 120 Hz | 99 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.512 (13.00mm) | - | Through Hole |
|
SEK4R7M400STCAP ALUM 4.7UF 20% 400V RADIAL |
2,244 | - |
|
Datasheet |
Bulk | SEK | Active | 4.7 µF | ±20% | 400 V | 56.47Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 55 mA @ 120 Hz | 99 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
SEK682M010STCAP ALUM 6800UF 20% 10V RADIAL |
2,037 | - |
|
Datasheet |
Bulk | SEK | Active | 6800 µF | ±20% | 10 V | 70mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.61 A @ 120 Hz | 1.932 A @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
SEK682M016STCAP ALUM 6800UF 20% 16V RADIAL |
3,453 | - |
|
Datasheet |
Bulk | SEK | Active | 6800 µF | ±20% | 16 V | 60mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.79 A @ 120 Hz | 2.148 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.417 (36.00mm) | - | Through Hole |
