Elektrolytkondensatoren aus Aluminium
| Foto | Herst. Teil # | Verfügbarkeit | Preis | Menge | Datenblatt | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SEK103M010STCAP ALUM 10000UF 20% 10V RADIAL |
2,040 | - |
|
Datasheet |
Bulk | SEK | Active | 10000 µF | ±20% | 10 V | 50mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.98 A @ 120 Hz | 2.376 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.417 (36.00mm) | - | Through Hole |
|
|
SEK103M016STCAP ALUM 10000UF 20% 16V RADIAL |
3,916 | - |
|
Datasheet |
Bulk | SEK | Active | 10000 µF | ±20% | 16 V | 50mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 2.884 A @ 120 Hz | 3.4608 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
SEK103M6R3STCAP ALUM 10000UF 20% 6.3V RADIAL |
3,462 | - |
|
Datasheet |
Bulk | SEK | Active | 10000 µF | ±20% | 6.3 V | 60mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.83 A @ 120 Hz | 2.196 A @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
SEK153M010STCAP ALUM 15000UF 20% 10V RADIAL |
3,559 | - |
|
Datasheet |
Bulk | SEK | Active | 15000 µF | ±20% | 10 V | 40mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 3.33 A @ 120 Hz | 3.996 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
SEK153M6R3STCAP ALUM 15000UF 20% 6.3V RADIAL |
3,411 | - |
|
Datasheet |
Bulk | SEK | Active | 15000 µF | ±20% | 6.3 V | 50mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 2.28 A @ 120 Hz | 2.736 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.417 (36.00mm) | - | Through Hole |
|
SEK220M160STCAP ALUM 22UF 20% 160V RADIAL |
2,377 | - |
|
Datasheet |
Bulk | SEK | Active | 22 µF | ±20% | 160 V | 9.05Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 130 mA @ 120 Hz | 208 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
SEK220M400STCAP ALUM 22UF 20% 400V RADIAL |
5,412 | - |
|
Datasheet |
Bulk,Bulk | SEK | Active | 22 µF | ±20% | 400 V | 12.06Ohm | 2000 Hrs @ 105°C | -40°C ~ 105°C | - | - | General Purpose | - | - | - | 0.197 (5.00mm) | 0.512 Dia (13.00mm) | 1.024 (26.00mm) | - | Through Hole |
|
SEK221M010STCAP ALUM 220UF 20% 10V RADIAL |
3,653 | - |
|
Datasheet |
Bulk | SEK | Active | 220 µF | ±20% | 10 V | 1.33Ohm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 180 mA @ 120 Hz | 216 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.433 (11.00mm) | - | Through Hole |
|
SEK221M160STCAP ALUM 220UF 20% 160V RADIAL |
3,132 | - |
|
Datasheet |
Bulk | SEK | Active | 220 µF | ±20% | 160 V | 900mOhm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 800 mA @ 10 kHz | - | 0.295 (7.50mm) | 0.630 Dia (16.00mm) | 1.417 (36.00mm) | - | Through Hole |
|
|
SEK221M6R3STCAP ALUM 220UF 20% 6.3V RADIAL |
2,703 | - |
|
Datasheet |
Bulk | SEK | Active | 220 µF | ±20% | 6.3 V | 1.57Ohm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 165 mA @ 120 Hz | 198 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.433 (11.00mm) | - | Through Hole |
|
SEK222M6R3STCAP ALUM 2200UF 20% 6.3V RADIAL |
2,119 | - |
|
Datasheet |
Bulk | SEK | Active | 2200 µF | ±20% | 6.3 V | 170mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 930 mA @ 120 Hz | 1.116 A @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.827 (21.00mm) | - | Through Hole |
|
|
SEK2R2M160STCAP ALUM 2.2UF 20% 160V RADIAL |
2,486 | - |
|
Datasheet |
Bulk | SEK | Active | 2.2 µF | ±20% | 160 V | 90.47Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 25 mA @ 120 Hz | 40 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.433 (11.00mm) | - | Through Hole |
|
|
SEK2R2M200STCAP ALUM 2.2UF 20% 200V RADIAL |
2,073 | - |
|
Datasheet |
Bulk | SEK | Active | 2.2 µF | ±20% | 200 V | 90.47Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 25 mA @ 120 Hz | 40 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.453 (11.50mm) | - | Through Hole |
|
|
SEK2R2M250STCAP ALUM 2.2UF 20% 250V RADIAL |
2,905 | - |
|
Datasheet |
Bulk | SEK | Active | 2.2 µF | ±20% | 250 V | 90.47Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 29 mA @ 120 Hz | 46.4 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.453 (11.50mm) | - | Through Hole |
|
SEK2R2M350STCAP ALUM 2.2UF 20% 350V RADIAL |
2,309 | - |
|
Datasheet |
Bulk | SEK | Active | 2.2 µF | ±20% | 350 V | 120.63Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 35 mA @ 120 Hz | 63 mA @ 10 kHz | - | 0.138 (3.50mm) | 0.394 Dia (10.00mm) | 0.453 (11.50mm) | - | Through Hole |
|
SEK330M350STCAP ALUM 33UF 20% 350V RADIAL |
2,829 | - |
|
Datasheet |
Bulk | SEK | Active | 33 µF | ±20% | 350 V | 8.04Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 195 mA @ 120 Hz | 351 mA @ 10 kHz | - | 0.295 (7.50mm) | 0.512 Dia (13.00mm) | 0.984 (25.00mm) | - | Through Hole |
|
|
SEK331M160STCAP ALUM 330UF 20% 160V RADIAL |
3,220 | - |
|
Datasheet |
Bulk | SEK | Active | 330 µF | ±20% | 160 V | 600mOhm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 850 mA @ 120 Hz | 1.36 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
SEK331M6R3STCAP ALUM 330UF 20% 6.3V RADIAL |
3,611 | - |
|
Datasheet |
Bulk | SEK | Active | 330 µF | ±20% | 6.3 V | 1.05Ohm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 200 mA @ 120 Hz | 240 mA @ 10 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.453 (11.50mm) | - | Through Hole |
|
|
SEK332M010STCAP ALUM 3300UF 20% 10V RADIAL |
2,396 | - |
|
Datasheet |
Bulk | SEK | Active | 3300 µF | ±20% | 10 V | 100mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 1.22 A @ 120 Hz | 1.464 A @ 10 kHz | - | 0.197 (5.00mm) | 0.512 Dia (13.00mm) | 0.984 (25.00mm) | - | Through Hole |
|
|
SEK332M050STCAP ALUM 3300UF 20% 50V RADIAL |
3,148 | - |
|
Datasheet |
Bulk | SEK | Active | 3300 µF | ±20% | 50 V | 470mOhm @ 120Hz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 2.478 A @ 120 Hz | 3.4692 A @ 10 kHz | - | 0.295 (7.50mm) | 0.709 Dia (18.00mm) | 1.654 (42.00mm) | - | Through Hole |
