Feste Induktoren
| Foto | Herst. Teil # | Verfügbarkeit | Preis | Menge | Datenblatt | Package/Case | Packaging | Series | ProductStatus | Type | Material-Core | Inductance | Tolerance | CurrentRating(Amps) | Current-Saturation(Isat) | Shielding | DCResistance(DCR) | Q@Freq | Frequency-SelfResonant | Ratings | OperatingTemperature | InductanceFrequency-Test | Features | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NS10145T4R7NNVFIXED IND 4.7UH 5.03A 17.28 MOHM |
3,471 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 4.7 µH | ±30% | 5.03 A | 6.69A | Shielded | 17.28mOhm Max | - | 27.8MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T5R6NNVFIXED IND 5.6UH 4.45A 21.72 MOHM |
3,549 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 5.6 µH | ±30% | 4.45 A | 5.85A | Shielded | 21.72mOhm Max | - | 26.3MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T6R8NNVFIXED IND 6.8UH 4.22A 27.6 MOHM |
3,335 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 6.8 µH | ±30% | 4.22 A | 5.05A | Shielded | 27.6mOhm Max | - | 23.1MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T100MNVFIXED IND 10UH 3.1A 32.4MOHM SMD |
2,025 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 3.1 A | 4.22A | Shielded | 32.4mOhm Max | - | 21.6MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T150MNVFIXED IND 15UH 3A 45.72 MOHM SMD |
2,120 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 3 A | 3.44A | Shielded | 45.72mOhm Max | - | 19MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T220MNVFIXED IND 22UH 2.3A 68.4MOHM SMD |
2,525 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 2.3 A | 2.87A | Shielded | 68.4mOhm Max | - | 13.5MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T221MNVFIXED IND 220UH 780MA 612MOHM SM |
2,268 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 220 µH | ±20% | 780 mA | 910mA | Shielded | 612mOhm Max | - | 4.2MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T331MNVFIXED IND 330UH 640MA 840MOHM SM |
3,761 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 330 µH | ±20% | 640 mA | 710mA | Shielded | 840mOhm Max | - | 3.3MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T471MNVFIXED IND 470UH 520MA 1.23OHM SM |
2,005 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 470 µH | ±20% | 520 mA | 610mA | Shielded | 1.23Ohm Max | - | 2.8MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T681MNVFIXED IND 680UH 420MA 1.88OHM SM |
2,738 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 680 µH | ±20% | 420 mA | 500mA | Shielded | 1.88Ohm Max | - | 2.3MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T102MNVFIXED IND 1MH 320MA 3.09 OHM SMD |
3,678 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 1 mH | ±20% | 320 mA | 410mA | Shielded | 3.09Ohm Max | - | 1.7MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10145T152MNVFIXED IND 1.5MH 270MA 4.44OHM SM |
2,173 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 1.5 mH | ±20% | 270 mA | 360mA | Shielded | 4.44Ohm Max | - | 1.5MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T1R5NNVFIXED IND 1.5UH 8.39A 7.2MOHM SM |
3,833 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 1.5 µH | ±30% | 8.39 A | 11.9A | Shielded | 7.2mOhm Max | - | 75.5MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T2R2NNVFIXED IND 2.2UH 7.61A 8.64 MOHM |
2,644 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 2.2 µH | ±30% | 7.61 A | 10A | Shielded | 8.64mOhm Max | - | 55.6MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T3R3NNVFIXED IND 3.3UH 6.49A 11.65 MOHM |
3,724 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 6.49 A | 8.5A | Shielded | 11.65mOhm Max | - | 40.6MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T4R7NNVFIXED IND 4.7UH 6.01A 13.44 MOHM |
2,686 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 4.7 µH | ±30% | 6.01 A | 7.4A | Shielded | 13.44mOhm Max | - | 33.4MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T6R8NNVFIXED IND 6.8UH 4.98A 19.08 MOHM |
2,261 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 6.8 µH | ±30% | 4.98 A | 6A | Shielded | 19.08mOhm Max | - | 24.2MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T100MNVFIXED IND 10UH 4.4A 24 MOHM SMD |
3,244 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 4.4 A | 4.49A | Shielded | 24mOhm Max | - | 20.2MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T150MNVFIXED IND 15UH 3.4A 37.2MOHM SMD |
3,436 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 3.4 A | 4.03A | Shielded | 37.2mOhm Max | - | 15.5MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
|
|
NS10155T220MNVFIXED IND 22UH 2.8A 51.6MOHM SMD |
3,450 | - |
|
Datasheet |
Nonstandard | Tape & Reel (TR),Cut Tape (CT) | NS | Obsolete | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 2.8 A | 3.37A | Shielded | 51.6mOhm Max | - | 11.3MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - |
