Automobilrelais
| Foto | Herst. Teil # | Verfügbarkeit | Preis | Menge | Datenblatt | Packaging | Series | ProductStatus | CoilType | CoilCurrent | CoilVoltage | ContactForm | ContactRating(Current) | SwitchingVoltage | MustOperateVoltage | MustReleaseVoltage | OperateTime | ReleaseTime | Features | MountingType | TerminationStyle |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
A2F1ACQ24VDC1.6DRELAY AUTOMOTIVE FLANGED SPST NO |
2,992 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 66.7 mA | 24VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 16.8 VDC | 2.4 VDC | 7 ms | 5 ms | Diode | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
A2H1ACQ12VDC1.6D50AMP AUTOMOTIVE RELAY STANDARD |
3,350 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 133.3 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Diode | Socketable | Plug In, Quick Connect - 0.250 (6.3mm) |
|
A2HF1ACQ12VDC1.6R50AMP AUTOMOTIVE RELAYS FLANGED |
3,774 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 150 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Resistor | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2F1ACQ24VDC1.9DRELAY AUTOMOTIVE FLANGED SPST NO |
2,820 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 79.2 mA | 24VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 16.8 VDC | 2.4 VDC | 7 ms | 5 ms | Diode | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2F1ASQ12VDC1.9DRELAY AUTOMOTIVE FLANGED SPST NO |
2,778 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 158.3 mA | 12VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 8.4 VDC | 1.2 VDC | 7 ms | 5 ms | Diode, Sealed - Fully | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2H1ACQ12VDC1.6R50AMP AUTOMOTIVE RELAY STANDARD |
3,428 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 150 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Resistor | Socketable | Plug In, Quick Connect - 0.250 (6.3mm) |
|
A11CSP24VDC1.2RELAY AUTO SPDT 24VDC PCB |
2,808 | - |
|
Datasheet |
Tube | A1 | Active | Non Latching | 50 mA | 24VDC | SPDT (1 Form C) | 30 A | 75VDC - Max | 18 VDC | 2.4 VDC | 10 ms | 7 ms | Sealed - Fully | Through Hole | PC Pin |
|
|
A2H1ASQ12VDC1.650AMP AUTOMOTIVE RELAY STANDARD |
3,756 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 133.3 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Fully | Socketable | Plug In, Quick Connect - 0.250 (6.3mm) |
|
A2H1ASP12VDC1.650AMP AUTOMOTIVE RELAY STANDARD |
2,355 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 133.3 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin |
|
|
A2HF1ASQ12VDC1.650AMP AUTOMOTIVE RELAYS FLANGED |
2,509 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 133.3 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Fully | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
A21ASQ24VDC1.9RELAY AUTOMOTIVE SPST NO 1A 24VD |
3,477 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 79.2 mA | 24VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 16.8 VDC | 2.4 VDC | 7 ms | 5 ms | Sealed - Fully | Socketable | Plug In, Quick Connect - 0.250 (6.3mm) |
|
|
A2F1ASQ24VDC1.9RELAY AUTOMOTIVE FLANGED SPST NO |
3,860 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 79.2 mA | 24VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 16.8 VDC | 2.4 VDC | 7 ms | 5 ms | Sealed - Fully | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
A2M1ACQ24VDC1.6RRELAY AUTOMOTIVE METAL BRACKET S |
2,867 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 66.7 mA | 24VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 16.8 VDC | 2.4 VDC | 7 ms | 5 ms | Resistor | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2HF1ACQ24VDC1.650AMP AUTOMOTIVE RELAYS FLANGED |
2,758 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 66.7 mA | 24VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 15.6 VDC | 2.4 VDC | 10 ms | 10 ms | - | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2M1ASQ12VDC1.9RRELAY AUTOMOTIVE METAL BRACKET S |
3,188 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 158.3 mA | 12VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 8.4 VDC | 1.2 VDC | 7 ms | 5 ms | Resistor, Sealed - Fully | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2M1ACQ24VDC1.9RRELAY AUTOMOTIVE METAL BRACKET S |
3,664 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 79.2 mA | 24VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 16.8 VDC | 2.4 VDC | 7 ms | 5 ms | Resistor | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2H1ACQ24VDC1.650AMP AUTOMOTIVE RELAY STANDARD |
2,759 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 66.7 mA | 24VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 15.6 VDC | 2.4 VDC | 10 ms | 10 ms | - | Socketable | Plug In, Quick Connect - 0.250 (6.3mm) |
|
A2HM1ACQ12VDC1.6D50AMP AUTOMOTIVE RELAY METAL BRA |
2,801 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 133.3 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Diode | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2HM1ACQ12VDC1.6R50AMP AUTOMOTIVE RELAY METAL BRA |
3,729 | - |
|
Datasheet |
Tray | A2H | Active | Non Latching | 150 mA | 12VDC | SPST-NO (1 Form A) | 50 A | 75VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Resistor | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
|
|
A2M1ACQ24VDC1.6DRELAY AUTOMOTIVE METAL BRACKET S |
2,242 | - |
|
Datasheet |
Tray | A2 | Active | Non Latching | 66.7 mA | 24VDC | SPST-NO (1 Form A) | 40 A | 75VDC - Max | 16.8 VDC | 2.4 VDC | 7 ms | 5 ms | Diode | Chassis Mount | Quick Connect - 0.250 (6.3mm) |
