Elektrolytkondensatoren aus Aluminium
| Foto | Herst. Teil # | Verfügbarkeit | Preis | Menge | Datenblatt | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HES462G400X5LCAP ALUM 4600UF 400V SCREW |
2,591 | - |
|
Datasheet |
Bulk | HES | Active | 4600 µF | 0%, +50% | 400 V | 25mOhm @ 120Hz | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 13 A @ 120 Hz | 15.99 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 5.625 (142.88mm) | - | Chassis Mount |
|
CGS144U075X8LCAP ALUM 140000UF 75V SCREW |
3,092 | - |
|
Datasheet |
Bulk | CGS | Active | 140000 µF | -10%, +75% | 75 V | 12mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 21.3 A @ 120 Hz | 27.69 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
MLS152M060EK0DCAP ALUM 1500UF 20% 60V FLATPACK |
2,266 | - |
|
Datasheet |
Bulk,Bulk | MLS | Active | 1500 µF | ±20% | 60 V | 106mOhm @ 120Hz | 10000 Hrs @ 85°C | -55°C ~ 125°C | Polar | - | General Purpose | 9.8 A @ 120 Hz | 11.5 A @ 20 kHz | - | 1.000 (25.40mm) | 1.500 L x 1.750 W (38.10mm x 44.45mm) | 0.500 (12.70mm) | - | Chassis Mount |
1C.jpg)
|
MLS331M200EK1CCAP ALUM 330UF 20% 200V FLATPACK |
2,762 | - |
|
Datasheet |
Bulk,Bulk | MLS | Active | 330 µF | ±20% | 200 V | 426mOhm @ 120Hz | 10000 Hrs @ 85°C | -55°C ~ 125°C | Polar | - | General Purpose | 4.9 A @ 120 Hz | 6.2 A @ 20 kHz | - | 1.000 (25.40mm) | 1.500 L x 1.750 W (38.10mm x 44.45mm) | 0.500 (12.70mm) | - | Through Hole |
|
MLS501M100EK0ACAP ALUM 500UF 100V FLATPACK |
3,060 | - |
|
Datasheet |
Bulk | MLS | Active | 500 µF | - | 100 V | - | - | - | - | - | General Purpose | - | - | - | 1.000 (25.40mm) | 1.500 L x 1.750 W (38.10mm x 44.45mm) | 0.500 (12.70mm) | - | Chassis Mount |
|
|
CGS433U150X8LCAP ALUM 43000UF 150V SCREW |
3,508 | - |
|
Datasheet |
Bulk | CGS | Active | 43000 µF | -10%, +75% | 150 V | 14mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 19.9 A @ 120 Hz | 25.87 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
|
HES562G350X5LCAP ALUM 5600UF 350V SCREW |
2,363 | - |
|
Datasheet |
Bulk | HES | Active | 5600 µF | 0%, +50% | 350 V | 24mOhm @ 120Hz | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 13.2 A @ 120 Hz | 16.236 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 5.625 (142.88mm) | - | Chassis Mount |
|
|
CGS193T250X8LCAP ALUM 19000UF 250V SCREW |
3,291 | - |
|
Datasheet |
Bulk | CGS | Active | 19000 µF | -10%, +50% | 250 V | 16mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 18.8 A @ 120 Hz | 28.2 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
|
CGS303T200X8LCAP ALUM 30000UF 200V SCREW |
3,364 | - |
|
Datasheet |
Bulk | CGS | Active | 30000 µF | -10%, +50% | 200 V | 11mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 22.7 A @ 120 Hz | 34.05 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
CGH362T500X5CCAP ALUM 3600UF 500V SCREW |
2,368 | - |
|
Datasheet |
Bulk | CGH | Active | 3600 µF | -10%, +50% | 500 V | 76.3mOhm @ 120Hz | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 7 A @ 120 Hz | - | - | - | 3.000 Dia (76.20mm) | 5.125 (130.18mm) | - | Chassis Mount |
|
|
500C123M450FG2HCAP ALUM 12000UF 20% 450V SCREW |
3,915 | - |
|
Datasheet |
Bulk | 500C | Active | 12000 µF | ±20% | 450 V | - | 5000 Hrs @ 85°C | -40°C ~ 95°C | Polar | - | General Purpose | - | - | - | 1.250 (31.75mm) | 3.500 Dia (88.90mm) | 8.687 (220.65mm) | - | Chassis Mount |
|
|
CGS153T250X5RCAP ALUM 15000UF 250V SCREW |
2,460 | - |
|
Datasheet |
Bulk | CGS | Active | 15000 µF | -10%, +50% | 250 V | 13mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 17.9 A @ 120 Hz | 26.85 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 5.875 (149.23mm) | - | Chassis Mount |
|
HES362G450X5CCAP ALUM 3600UF 450V SCREW |
3,317 | - |
|
Datasheet |
Bulk | HES | Active | 3600 µF | 0%, +50% | 450 V | 28mOhm @ 120Hz | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 11.7 A @ 120 Hz | 14.391 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 5.125 (130.18mm) | - | Chassis Mount |
|
|
CGS253T200X8LCAP ALUM 25000UF 200V SCREW |
3,550 | - |
|
Datasheet |
Bulk | CGS | Active | 25000 µF | -10%, +50% | 200 V | 15mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 19.9 A @ 120 Hz | 29.85 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
|
520C143T400FG2DCAP ALUM 14000UF 400V SCREW |
2,788 | - |
|
Datasheet |
Bulk | 520C | Active | 14000 µF | -10%, +50% | 400 V | 13.8mOhm @ 120Hz | 8000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 28.8 A @ 120 Hz | - | - | 1.250 (31.75mm) | 3.500 Dia (88.90mm) | 8.687 (220.65mm) | - | Chassis Mount |
|
|
CGS214U063X8LCAP ALUM 210000UF 63V SCREW |
3,477 | - |
|
Datasheet |
Bulk | CGS | Active | 210000 µF | -10%, +75% | 63 V | 12mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 21.3 A @ 120 Hz | 27.69 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
|
CGS352T500X5LCAP ALUM 3500UF 500V SCREW |
3,020 | - |
|
Datasheet |
Bulk | CGS | Active | 3500 µF | -10%, +50% | 500 V | 30mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 12.1 A @ 120 Hz | 18.15 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 5.625 (142.88mm) | - | Chassis Mount |
|
CGH412T500X5LCAP ALUM 4100UF 500V SCREW |
2,671 | - |
|
Datasheet |
Bulk | CGH | Active | 4100 µF | -10%, +50% | 500 V | 67.8mOhm @ 120Hz | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 7.7 A @ 120 Hz | - | - | - | 3.000 Dia (76.20mm) | 5.625 (142.88mm) | - | Chassis Mount |
|
|
CGS963U100X8LCAP ALUM 96000UF 100V SCREW |
2,882 | - |
|
Datasheet |
Bulk,Bulk | CGS | Active | 96000 µF | -10%, +75% | 100 V | 13mOhm @ 120Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 20.9 A @ 120 Hz | 27.17 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
|
CGH103T350X8LCAP ALUM 10000UF 350V SCREW |
3,916 | - |
|
Datasheet |
Bulk | CGH | Active | 10000 µF | -10%, +50% | 350 V | 20.7mOhm @ 120Hz | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 16.6 A @ 120 Hz | 20.418 A @ 10 kHz | - | - | 3.000 Dia (76.20mm) | 8.625 (219.08mm) | - | Chassis Mount |
