Elektrolytkondensatoren aus Aluminium
| Foto | Herst. Teil # | Verfügbarkeit | Preis | Menge | Datenblatt | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EEE-1HS2R2SRCAP ALUM 2.2UF 20% 50V SMD |
2,200 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 2.2 µF | ±20% | 50 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 8 mA @ 120 Hz | 13.6 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
|
EEE-1HSR22SRCAP ALUM 0.22UF 20% 50V SMD |
3,370 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 0.22 µF | ±20% | 50 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 2 mA @ 120 Hz | 3.4 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
|
EEE-1HSR47SRCAP ALUM 0.47UF 20% 50V SMD |
2,247 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 0.47 µF | ±20% | 50 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 5 mA @ 120 Hz | 8.5 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
EEE-1JA100PCAP ALUM 10UF 20% 63V SMD |
3,128 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 10 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | - | - | - | - | - | - | - | Surface Mount |
|
|
EEE-1VA330UPCAP ALUM 33UF 20% 35V SMD |
2,899 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 33 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | - | - | - | - | - | - | - | Surface Mount |
|
|
EEE-1VS2R2SRCAP ALUM 2.2UF 20% 35V SMD |
3,110 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 2.2 µF | ±20% | 35 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 8 mA @ 120 Hz | 13.6 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
|
EEE-1VS3R3SRCAP ALUM 3.3UF 20% 35V SMD |
2,851 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 3.3 µF | ±20% | 35 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 10 mA @ 120 Hz | 17 mA @ 10 kHz | - | - | 0.118 Dia (3.00mm) | 0.213 (5.40mm) | 0.130 L x 0.130 W (3.30mm x 3.30mm) | Surface Mount |
|
|
EEE-2AA3R3PCAP ALUM 3.3UF 20% 100V SMD |
2,928 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 3.3 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 50 mA @ 120 Hz | 85 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEE-2AA4R7PCAP ALUM 4.7UF 20% 100V SMD |
2,087 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 4.7 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 80 mA @ 120 Hz | 136 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.402 (10.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
|
EEE-2AA4R7UPCAP ALUM 4.7UF 20% 100V SMD |
3,649 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | S | Obsolete | 4.7 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 50 mA @ 120 Hz | 85 mA @ 10 kHz | - | - | 0.315 Dia (8.00mm) | 0.244 (6.20mm) | 0.327 L x 0.327 W (8.30mm x 8.30mm) | Surface Mount |
|
EEU-EB1A101CAP ALUM 100UF 20% 10V RADIAL |
3,615 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 100 µF | ±20% | 10 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 105 mA @ 120 Hz | 136.5 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1E470CAP ALUM 47UF 20% 25V RADIAL |
3,358 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 47 µF | ±20% | 25 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 78 mA @ 120 Hz | 101.4 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1V330CAP ALUM 33UF 20% 35V RADIAL |
3,943 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 33 µF | ±20% | 35 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 66 mA @ 120 Hz | 85.8 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1H220CAP ALUM 22UF 20% 50V RADIAL |
3,643 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 22 µF | ±20% | 50 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 55 mA @ 120 Hz | 71.5 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
EEU-EB1H470CAP ALUM 47UF 20% 50V RADIAL |
2,386 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 47 µF | ±20% | 50 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 87 mA @ 120 Hz | 113.1 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1JR47CAP ALUM 0.47UF 20% 63V RADIAL |
3,003 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 0.47 µF | ±20% | 63 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 6 mA @ 120 Hz | 9.9 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1J100CAP ALUM 10UF 20% 63V RADIAL |
3,854 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 10 µF | ±20% | 63 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 46 mA @ 120 Hz | 75.9 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1J1R0CAP ALUM 1UF 20% 63V RADIAL |
2,264 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 1 µF | ±20% | 63 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 12 mA @ 120 Hz | 19.8 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1J2R2CAP ALUM 2.2UF 20% 63V RADIAL |
3,755 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 2.2 µF | ±20% | 63 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 22 mA @ 120 Hz | 27.22 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.630 (16.00mm) | - | Through Hole |
|
|
EEU-EB1J220CAP ALUM 22UF 20% 63V RADIAL |
3,984 | - |
|
Datasheet |
Bulk | EB-A | Obsolete | 22 µF | ±20% | 63 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 55 mA @ 120 Hz | 71.5 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.630 (16.00mm) | - | Through Hole |
